The JL Audio 13W3v3 Subwoofer is a great choice if you have the space, it makes a tremendous sense to maximize your subwoofer system's piston area to enhance efficiency (and output). It gets even better when the larger driver delivers additional power handling and excursion. For the preceding reasons, the 13W3v3 can be the best choice for those seeking high output with great sound quality at medium power levels.
As with the smaller W3v3's, several exclusive JL Audio technologies and proprietary assembly techniques are applied to the 13W3v3 to enhance linearity and reliability.
The 13W3v3-2 is best used with amplifier power in the 150W - 600W range and is optimized to operate in a moderate size 49.6 L sealed enclosure, or a 70.8 L ported enclosure.
|SUBWOOFER||13W3v3 - 2 Ohm||13W3v3 - 4 Ohm|
|Free Air Resonance (Fs):||24.70 Hz||23.66 Hz|
|Electrical “Q” (Qes):||0.544||0.465|
|Mechanical “Q” (Qms):||6.936||6.774|
|Total Speaker “Q” (Qts):||0.504||0.435|
|Equivalent Compliance (Vas):||131.26 litres||135.74 litres|
|One-way, Linear Excursion (Xmax):||15.5 mm||15.5 mm|
|Efficiency (1W/1m):||87.63 dB SPL||87.90 dB SPL|
|Effective Piston Area (Sd):||0.0670 m2||0.0670 m2|
|DC Resistance (Re):||1.659 ohm||3.569 ohm|
|Nominal Impedance:||2 ohm||4 ohm|
|Power Handling (continuous):||600 W||600 W|
