JL Audio MX280/4 - 4 Channel - Class D Amplifier

£269.99

In Stock
Free Shipping Over £100 to United Kingdom

Product Details

Engineered specifically for powersports applications, the JL Audio MX280/4 - 4 Channel - Class D Amplifier employs our high-speed NexD™ switching design to deliver plenty of clean power, without straining charging systems. Its tiny, cast aluminum chassis is highly resistant to corrosion, with an IPX7 water-resistance rating, making it perfect for motorcycles, ATV’s or other utility vehicles.

Generating a solid 50W x 4 into 4 ohms (14.4V, 1% THD), the MX280/4 is fully bridgeable, so it can be used as a 3-channel amplifier, or as a 2-channel amplifier producing a potent 140W x 2 into 4 ohms.

Other features include independent front and rear crossovers with selectable full-range, high-pass or low-pass filter controls and a dual-range input section that accepts a wide range of input voltage levels, from line-level all the way to high-power speaker level signals.

This amplifier features a rugged powder-coated finish, a gasketed cover for the controls and stainless steel hardware for durability.

Technical Specifications

Rated Continuous (RMS) Power @ 14.4 V

@ 4 Ω - 50 W RMS x 4

@ 2 Ω - 70 W RMS x 4

Bridged @ 4Ω - 140 W RMS x 2

Rated Continuous (RMS) Power @ 12.5 V

@ 4 Ω - 36 W RMS x 4

@ 2 Ω - 52 W RMS x 4

Bridged @ 4Ω - 100 W RMS x 2

Frequency Response 20 Hz - 20 kHz (+0, -1dB)
S/N Ratio, referred to highest rated power >89.5 dB below rated power (A-weighted, 20 Hz - 20 kHz noise bandwidth)
S/N Ratio, referred to 1 W >68 dB (A-weighted, 20 Hz - 20 kHz noise bandwidth)
Damping Factor @ 4 Ω >60 / 50 Hz
Damping Factor @ 2 Ω >30 / 50 Hz
THD+N @ Rated Power <1% @ 2 Ω per Ch.
Input Voltage Range @ RCA Inputs Switchable from 250 mV - 4 V RMS (Low) to 750 mV - 15 V RMS (High)
Min.Copper Power / Ground Wire Gauge 8 AWG wire
Fuse Rating 35 A (AFS, AGU or MaxiFuse™)

Dimensions

  • Height (H): 1.77 in / 45 mm
  • Width (W): 8.66 in / 220 mm
  • Depth (D): 3.09 in / 78.5 mm
  • Net Weight: 3.18 lb / 1.44 kg

Further Information

JL Audio MX280/4 - 4 Channel - Class D Amplifier - User Manual
