The BlackVue DR770X-1CH represents the benchmark in the single-channel dash cam category, the choice for the power-user who demands the ultimate in terms of video quality and next-generation connected features.
With Full HD 1080p performance, the DR770X-1CH provides class-leading protection for your vehicle by recording fluid 60 frames per second video footage via an ultra-wide lens with a 139° viewing angle.
A Sony STARVIS image sensor ensures the best possible image quality under any lighting conditions. Also included is GPS logging, Wi-Fi, Cloud-connectivity and impact and motion detection.
The DR770X is also compatible with BlackVue Cloud – a unique suite of LIVE app-based features that remotely connecting you with your vehicle, providing additional functionality including Live View, Remote Video Playback, Video Backup, Realtime Tracking and Emergency Notification Alerts.
The DR770X is upgradable to full 4G always-on Cloud Connectivity, with the addition of the CM100LTE external connectivity module and supplied data SIM, meaning that you are always connected to your dash cam via the BlackVue app, and always able to receive notifications and remotely view video clips in the event of an incident.
For extended recording times simply add a Power Magic Ultra Battery B-130X, B-124X or B-112 battery.
Key Features
- Full HD 1080p video at 60 frames per second
- Enhanced Night Vision for optimal clarity
- Loop Recording & Event Overwrite Protection
- Intelligent Parking Mode for 24/7 recording
- Always-On 4G with optional CM100GLTE
- BlackVue Cloud LIVE features
- GPS adds location and speed data
- Wi-Fi for wireless connection to smartphone
- iOS/Android App, PC/Mac desktop viewer
What's in the Box?
- Black DR770x Front Camera
- Cigarette Lighter Power Cable
- Hardwiring Power Cable
- Quick Start Guide
- Double Sided Tape for the Front Mounting Bracket
- Cable Clips x5
- Micro SD Card Reader
- Micro SD Card
- Pry Tool
Technical Specification Highlights
Product Dimensions | Front: W 118.5 mm x H 36 mm / 104 g |
---|---|
Memory Support | microSD card from 32GB up to 256GB |
Recording Modes | Normal Recording |
Event Recording (when impact is detected in noraml and parking mode) | |
Manual Recording and Parking Recording (when motion is detected) | |
Camera | Front: STARVIS CMOS Sensor (Approx 2.1M Pixel) |
Resolution Frame Rate | Full HD @60fps |
Video Codec | H.264 (AVC) |
Image Quality | Highest (Extreme), Highest, High, Normal |
Video Compression Mode | MP4 |
Wi-Fi | Built-in (802.11 b.g.n) |
GPS | Built-in (Dual band: GPS, GLONASS) |
Recording Times
Memory Capacity | Image Quality | Resolution (Front) |
---|---|---|
Full HD @60fps | ||
64GB | Highest (Extreme) | 5 HR 20 MIN |
Highest | 11 HR | |
High | 13 HR | |
Normal | 16 HR | |
128GB | Highest (Extreme) | 10 HR 40 MIN |
Highest | 22 HR | |
High | 26 HR | |
Normal | 32 HR | |
256GB | Highest (Extreme) | 21 HR 20 MIN |
Highest | 44 HR | |
High | 52 HR | |
Normal | 64 HR |
